Blackmagic Design DeckLink Studio 4K

Part Number: BDLKSTUDIO4K

DeckLink Studio 4K
  • DeckLink Studio 4K

Price:

$565.25

Specifications

Ports 5
Interface SD/HD/2K/4K
Weight 5.9 Oz
Dimensions 5.55 Inches
Compatibility Compatible with 4, 8, and 16 lane PCI Express slots
Warranty 3 Years
Product Line Capture and Playback

Blackmagic Design DeckLink Studio 4K

If you work with a wide range of analog video and audio gear, and need to move seamlessly between SD, HD, 2K and Ultra HD, then DeckLink Studio 4K is perfect! DeckLink Studio 4K includes a massive number of analog and digital video connections including SD/HD/Ultra HD 6G-SDI, HDMI 1.4b, SD/HD component, composite, S-video, 4 ch balanced analog audio, 2 ch AES/EBU switchable to 6 ch out, black burst and tri-sync reference input, RS-422 deck control connections, keying in SD and a hardware down converter. Perform editing, paint and broadcast design and more with the ultimate future proof design!

  • SDI Video Input: 1 x 10-bit SD/HD/2K/4K. Supports 6 Gb/s 4:2:2 and 3 Gb/s 4:4:4
  • SDI Video Output: 1 x 10-bit SD/HD/2K/4K. Supports 6 Gb/s 4:2:2 and 3 Gb/s 4:4:4
  • Analog Video Input: 1 x Component YUV on 3 BNCs, 1 x Composite, 1 x S-Video. Component supports HD and SD.
  • Analog Video Output: 1 x Component YUV on 3 BNCs, 1 x Composite, 1 x S-Video, 1 x SD-SDI. Component supports HD and SD.
  • HDMI Video Input: 1 x HDMI type A connector
  • HDMI Video Output: 1 x HDMI type A connector
  • Analog Audio Input: 4 Channels of professional balanced analog audio via 1/4" jack connectors.
  • Analog Audio Output: 4 Channels of professional balanced analog audio via 1/4" jack connectors. Channels 3 & 4 can switch to AES/EBU outputs.
  • AES/EBU Audio Input: 2 Channels unbalanced with sample rate converter.
  • AES/EBU Audio Output: 2 Channels unbalanced. Analog outputs 3 and 4 can switch to AES/EBU outputs for audio 3 & 4 and 5 & 6 output. This provides a total of 6 AES/EBU output audio channels when using this feature.
  • SDI Audio Input: 16 Channels embedded in HD/2K/4K. 8 Channels embedded in SD.
  • SDI Audio Output: 16 Channels embedded in HD/2K/4K. 8 Channels embedded in SD.
  • HDMI Audio Input: 8 Channels embedded in SD, HD, 4K.
  • HDMI Audio Output: 8 Channels embedded in SD, HD, 4K
  • Sync Input: Blackburst in SD, 720p50, 720p59.94, 1080i50 and 1080i59.94 formats or Tri-Sync in any HD, 2K or 4K format.
  • Device Control: Sony™ compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control.
  • Computer Interface: PCI Express 4 lane generation 1, compatible with 4,8 and 16 lane PCIe Slots.
  • Codecs Supported: AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, Apple ProRes 4444, Apple ProRes 422 (HQ), Apple ProRes 422, Apple ProRes (LT), Apple ProRes 422 (Proxy), Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10 bit 4:4:4.
  • Software Included: Media Express, Disk Speed Test, LiveKey, Blackmagic System Preferences and Blackmagic driver on Mac OS X. Media Express, Disk Speed Test, LiveKey, Blackmagic Control Panel and Blackmagic driver on Windows 7 and Windows 8. Media Express, Blackmagic Control Panel and Blackmagic driver on Linux.
  • Internal Software Upgrade: Firmware built into software driver. Loaded at system start or via updater software.
  • Physical Installation: PCI Express 4 lane generation 1, compatible with 4, 8, 16 lane PCI Express slots on Mac OS X, Windows and Linux. Please check the Support pages to see the full system requirements.
  • SD Format Support: 625/25 PAL, 525/29.97 NTSC
  • HD Format Support: 720p50, 720p59.94, 720p60, 1080PsF23.98, 1080p23.98, 1080PsF24, 1080p24, 1080PsF25, 1080p25, 1080PsF29.97, 1080p29.97, 1080PsF30, 1080p30, 1080i50, 1080p50, 1080i59.94, 1080p59.94, 1080i60, and 1080p60
  • 2K Format Support: 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25
  • 4K Format Support: 3840x2160p23.98, 3840x2160p24, 3840x2160p25, 3840x2160p29.97, 3840x2160p30, 4096x2160p23.98, 4096x2160p24, 4096x2160p25
  • SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M SMPTE 372M, SMPTE 425M ITU-R BT.656 and ITU-R BT.601
  • SDI Metadata Support: VITC read for 3:2 pulldown removal. VANC capture and playback using up to 3 lines of video in file. HD RP188. Closed captioning.
  • Audio Sampling: Television standard sample rate of 48 kHz at 24 bit.
  • Video Sampling: 4:2:2 and 4:4:4 (4K is 4:2:2)
  • Color Precision: 10-bit
  • Color Space: REC 601, REC 709
  • HDMI Configuration: HDMI automatically configures to connected display.
  • HDMI Resolution: Pixel for pixel up to 4K resolutions.
  • HDMI Color Precision: 10-bit RGB in HD, 10-bit YUV in 4K
  • Multiple Rate support: HDMI and SDI video connections are switchable between SD/HD/2K and UHD. Component analog video connections are switchable between SD and HD.
  • Copy Protection: HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
  • Colorspace Conversion: Hardware based real time.
  • HD Down Conversion: Built in, high quality hardware down converter outputs HD-SDI on SDI output, SD on SD-SDI, Composite and S-Video outputs when working in HD video formats on playback. Switch analog video to Component and choose HD or SD output. Selectable between letterbox, anamorphic 16:9 and center cut 4:3 styles.
  • HD Up Conversion: Software based up conversion from SD to 720HD or 1080HD on capture. Selectable between 4:3 pillarbox, 14:9 pillarbox and 16:9 zoom.
  • Cross Conversion: Software based cross conversion from 720HD to 1080HD and 1080HD to 720HD on playback.
  • Real Time Effects: Apple Final Cut Pro™ internal effects. Adobe® Premiere Pro CC® Mercury Playback Engine effects. Avid Media Composer™ internal effects. DaVinci Resolve.
  • Operating Systems: Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks or later / Windows 7 or Windows 8 / Linux
  • EMC Certifications: FCC, CE and C-Tick
  • 5.55 in. / 5.9 oz.
  • Operating Temperature: 5° to 40° C (32° to 104° F)
  • Storage Temperature: -20° to 45° C (-4° to 113° F)
  • Relative Humidity: 0% to 90% non-condensing
  • What's Included:
    • DeckLink Studio 4K
    • SD Card
    • Breakout cable for analog and RS-422 control
    • HDMI bracket
  • 3 Year Limited Manufacturer's Warranty



  • TOL Part #: BMD-BDLKSTUDIO4K
  • Manufacturer's Part #: BDLKSTUDIO4K
  • Model: DeckLink Studio 4K
  • Product ID: 5856
